| Item | Unit | TP600P |
| X/Y/Z Travel | mm | 600*400*330 |
| Worktable Size | mm | 700*420 |
| Worktable Load | kg | 250 |
| Distance from Spindle Center to Column Guide Rail Surface | mm | 464 |
| Distance from Spindle Face to Table Surface | mm | 150-480 |
| T-slot on the Worktable | mm | 14T*3*125 |
| Spindle Taper/Bore Diameter | BT30(Φ100) | |
| Spindle Rotate Speed | r/min | 20000 |
| (X/Y/Z) Rapid Traverse | m/min | 48 |
| Ball Screw | mm | XY：28*16 ； Z：32*16 |
| Linear Guide(Rail Width/Number of Blocks) | mm | XYZ:30*2 |
| Bare Machine Weight | kg | 约2300 |
1. Three axes use Taiwanese brand C3 grade ball screws
2. Three axes use Taiwanese brand roller linear guides
3. Three axes use P4 grade bearings
4. Three axes use Taiwanese-made "Speedcn" couplings
5. Three axes use Taiwanese-made "Speedcn" protective covers
6. BBT30 -Φ100- 20000rpm direct drive “Speedcn” spindle
7. BT30- 21T rotatory “Yitai Speedcn” servo tool magazine
8. Volumetric oil injector
9. Toolbox and adjustment tools
10. Full set of sheet metal parts
1. Vertical column height increased by 150mm
2. Taiwanese ball screw/linear guide are optional
