| Item | Unit | T13 |
| X/Y/Z Trav | mm | 1300*650*450 |
| Worktable Size | mm | 1400*600 |
| Worktable Load | kg | 500 |
| Distance from Spindle Center to Column Guide Rail Surface | mm | 705 |
| Distance from Spindle Face to Table Surface | mm | 150-600 |
| T-slot on the Worktable | mm | 18T*5*100 |
| Spindle Taper/Bore Diameter | BT30(Φ110) | |
| Spindle Rotate Speed | r/min | 12000 |
| (X/Y/Z) Rapid Traverse | m/min | 36 |
| Ball Screw | mm | XYZ：40*12 |
| Linear Guide(Rail Width/Number of Blocks) | mm | X：45*6；YZ：45*4 |
| Bare Machine Weight | kg | about 4500 |
1. Three axes use Japanese “THK” C3 grade ball screws
2. Three axes use Japanese “THK” linear guides
3. Three axes use P4 grade bearings
4. Three axes use Taiwanese-made "Speedcn" couplings
5. Three axes use Taiwanese-made "Speedcn" protective covers
6. BBT30 -Φ110- 12000rpm direct drive “Speedcn” spindle (15000/20000/24000rpm for option)
7. BT30- 21T rotatory “Yitai Speedcn” servo tool magazine
8. Volumetric oil injector
9. Toolbox and adjustment tools
1. BBT30 Φ110 12000/15000rpm direct drive “Speedcn” spindle
2. BBT30 - Φ110 – 20000rpm direct drive “Speedcn” spindle
3. BT30-26T “Yitai Speedcn” servo tool magazine
